Erkek/Dişi Headerlar

Description

Erkek/Dişi Headerlar

0.8mm Erkek Header

Özellikler

• Anma Akımı :0.5 Amper
  İzolasyon Direnci: 500Mohm Min
  Dielektrik Dayanım: 200 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

0.8mm Dişi Header

Özellikler

• Anma Akımı :0.5 Amper
  İzolasyon Direnci: 500Mohm Min
  Dielektrik Dayanım: 200 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Fosfor bronz
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

1.00mm Erkek Header

Özellikler

• Anma Akımı :1.0 Amper
  İzolasyon Direnci: 300Mohm Min
  Dielektrik Dayanım: 200 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

1.00mm Dişi Header

Özellikler

• Anma Akımı :1.0 Amper
  İzolasyon Direnci: 300Mohm Min
  Dielektrik Dayanım: 200 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: – -40C  den +105C

Malzemeler

• İletişim Malzemesi: Fosfor bronz
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

1.27mm Erkek Header

Özellikler

• Anma Akımı :1.0 Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 300 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

1.27mm Dişi Header

Özellikler

• Anma Akımı :1.0 Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 300 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

2.00mm Erkek Header

Özellikler

• Anma Akımı :2.0 Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 500 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

2.00mm Dişi  Header

Özellikler

• Anma Akımı :2.0 Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 500 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Fosfor bronz
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

2.54mm Erkek  Header

Özellikler

• Anma Akımı :3.0 Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 600 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

2.54mm Dişi  Header

Özellikler

• Anma Akımı :3.0 Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 600 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi:Fosfor Bronz
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

3.96 mm Erkek  Header

Özellikler

• Anma Akımı :7.9  Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 1500 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

3.96 mm Dişi Header

Özellikler

• Anma Akımı :7.9  Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 1500 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Fosfor broz
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

5.08 mm Erkek  Header

Özellikler

• Anma Akımı :7.9  Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 1500 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı: -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

5.08 mm Dişi  Header

Özellikler

• Anma Akımı :7.9  Amper
  İzolasyon Direnci: 1000Mohm Min
  Dielektrik Dayanım: 1500 VAC
  Temas Direnci: 20mOhm Max
  Çalışma Sıcaklığı:  -40C  den +105C

Malzemeler

• İletişim Malzemesi: Pirinç
  Yalıtım Malzemesi: Polyester, UL 94V-0
  LCP/NL6T
  Tüm malzeme RoHS ve Reach Uyumlu
  Halojensiz

Ürünler:

• Pitch 0.8mm(0.031”) HMFMH10-Series H=1.00mm(0.039”)
• Pitch 0.8mm(0.031”) HMFdm10-Series H=1.00mm(0.039”)
• Pitch 0.8mm(0.031”) HMFMH10-Series H=1.00mm(0.039”)
• Pitch 0.8mm(0.031”) HFFDM30-Series H=3.00mm(0.118”)
• Pitch 0.8mm(0.031”) HMFDS10-Series H=1.00mm(0.039”)
• Pitch 0.8mm(0.031”) HMFDP13-Series H=1.3mm(0.051”)
• Pitch 1.0mm(0.039”) HMGSSH10/HMGSSG15 H=1.0/1.5mm(0.039”/0.059”)
• Pitch 1.0mm(0.039”) HMGSR10/HMGSR15 H=1.0/1.5mm(0.039”/0.059”)
• Pitch 1.0mm(0.039”) HMGSV10 H=1.0mm(0.039”)
• Pitch 1.0mm(0.039”) HMGSP15 H=1.5mm(0.059”)
• Pitch 1.0mm(0.039”) HMGDS10/HMGDS15 H=1.0/1.5mm(0.039”/0.059”)
• Pitch 1.0mm(0.039”) HMGDR10/HMGDR15 H=1.0/1.5mm(0.039”/0.059”)
• Pitch 1.0mm(0.039”) HMGDM10/HMGDM15 H=1.0/1.5mm(0.039”/0.059”)
• Pitch 1.0mm(0.039”) HMGDSH10/HMGDSH15 H=1.0/1.5mm(0.039”/0.059”)
• Pitch 1.0mm(0.039”) HGFSS20 H=2.0mm(0.079”)
• Pitch 1.0mm(0.039”) HFGSP35 H=3.5mm(0.138”)
• Pitch 1.0mm(0.039”) HFGSVB20 H=2.0mm(0.079”)
• Pitch 1.0mm(0.039”) HFGDM20 H=2.0mm(0.079”)
• Pitch 1.27×2.54mm(0.05”x0.1”) SQ:0.46 HMJDSH17/HMJDSH25 H=1.7/2.5mm(0.067”/0.098”)
• Pitch 1.27×2.54mm(0.05”x0.1”) SQ:0.46 HMJDMH17/HMJDMH25 H=1.7/2.5mm(0.067”/0.098”)
• Pitch 1.27×1.27mm(0.05”x0.5”) HMIDP10/HMIDP15/HMIDP17/HMIDP17/HMIDP20/HMIDP25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039”/0.059”/0.067”/0.079”/0.098”)
• Pitch 1.27mm(0.05”) HFISS20/HFISS34/HFISS43 H=2.0/3.4/4.3mm (0.079”/0.134”/0.169”)
• Pitch 1.27mm(0.05”) HFISR20/HFISR34/HFISR4 H=2.0/3.4/4.3mm (0.079”/0.134”/0.169”)
• Pitch 1.27mm(0.05”) HFISV20/HFISV34/HFISV43 H=2.0/3.4/4.3mm (0.079”/0.134”/0.169”)
• Pitch 1.27mm(0.05”) HFIDS34/HFIDS44 H=3.4/4.4mm (0.134”/0.173”)
• Pitch 1.27mm(0.05”) HFIDR44 H=4.4mm (0.173”)
• Pitch 1.27mm(0.05”) HFIDM34/HFIDM44 H=3.4/4.4mm (0.134”/0.173”)
• Pitch 1.27mm(0.05″) HFIDM20 H=2.0 mm(0.079″)
• Pitch 1.27mm(0.05”) HFIDR52 H=5.2mm(0.205”)
• Pitch 1.27mm(0.05″) HFIDM 52 H=5.2 mm(0.205″)
• Pitch 1.27 mm(0.05″) HFIDM44-T050 H=4.4mm(0.173″)
• Pitch 1.27mm(0.05″) HFIDM44-P048 H=4.4mm(0.173″)
• Pitch 1.27mm(0.05″) HFJSS46 H=4.6 mm(0.181 “)
• Pitch 1.27×2.54mm(0.05″x0.1 “) HFJDS46 H=4.6mm(0.181 “)
• Pitch 1.27mm(0.05″) HFJSS85 H=8.5mm(0.335”)
• Pitch 1.27×2.54 mm(0.05″x0.1 “) HFJ DS85 H=8.5mm(0.335”)
• Pitch 1.27×2.54mm(0.05″x0.1 ”) HFJDM 45 / HFJDM 57 H=4.5/5 .7mm
• Pitch 1.27mm(0.05″) SQ : 0. 46 HMJSS17/HMJSS25 H=1.7/2.5mm(0.067″/0.098″)
• Pitch 1.27mm(0.05″) HMISS10/HMISS15/HMISS17/HMISS20/HMISS25 H=1.0/1.511.7/2.0/2.5/mm (0.039″/0.059″/0.067″/0.079″/0.098″)
• Pitch 1.27mm(0.05″) SQ: 0. 46 HMJSR17/HMJSR25 H=1. 7/2.5mm (0.067″/0.098″ )
• Pitch 1.27mm(0.05″) HMISR10/HMISR15/HMISR17/HMISR20/HMISR25
• H=1.0/1.5/1.7/2.0/2.5/mm (0.039″/0.059″/0.067″/0.079″/0.098″)
• Pitch 1.27mm(0.05″) HMISN10/HMISN15/HMISN17/HMISN20/HMISN25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039″/0.059″/0.067″/0.079″/0.098″)
• Pitch 1.27mm(0.05”)HMISSH10/HMISSH15/HMISSH17/HMISSH20/HMISSH25  H=1.0/1.511 .II’2.0/2.5Imm (0.039″/0.059″/0.067″/0.079″/0.098″)
• Pitch 1.27mm(0.05″) HMISRH10/HMISRH15/HMISRH17/HMISRH20/HMISRH25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039″/0.059″/0.067″/0.079″/0.098″)
• Pitch 1.27mm(0.05″) HMISVH10/HMISVH15/HMISVH17/HMISVH20/HMISVH25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039’0.059′ 0.067’0.079′ 0.098′)
• Pitch 1.27×2.54 mm(0.05″x0.1 “) SQ: 0. 46 HMJDS17/HMJDS25 H=1. 7/2.5mm (0. 067″/0. 098” )
• Pitch 1.27×1.27mm(0.05″x0.05″) HMIDS10/HMIDS15/HMIDS17/HMIDS20IHMIDS25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039″/0.059″/0.067″/0.079″/0.098″)
• Pitch 1.27×2.54mm(0.05’*x0.1″) SQ: 0. 46 HMJDR17/HMJ DR25 H=1.7/2. 5mm(0. 067″/0.098″ )
• Pitch 1.27×1.27mm(0.05″x0.05″) HMIDR10/HMIDR15/HMIDR17/HMIDR20/HMIDR25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039″/0.059″/0.067″/0.079″/0.098″)
• Pitch 1.27×2.54mm(0.05″x0.1″) SQ: 0. 46 HMJDM17/HMJDM25 H=1.7/2.5mm(0.067″/0.098″)
• Pitch 1.27×1.27 mm(0.05″x0.05″) HMIDM10/HMIDM15/HMIDM17/HMIDM20/HMIDM25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039″/0.059″/0.067″/0.079’*/0.098″ )
• Pitch 1.27×1.27 mm(0.05″x0.05″) HMIDSH10/HMIDSH15IHMIDSH17/HMIDSH20/HMIDSH25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039′ 0.059′ 0.067’0.079′ 0.098′
• Pitch J.27×1.27 mm(0.05″x0.05″) HMIDRH10/HMIDRH15/HMIDRH17/HMIDRH20/HMIDRH25 H=1.0/1.5/1. III.0/2.5lmm (0.039′ 0.059′ 0.067’0.079′ 0.098″)
• Pitch 1.27×1.27 mm(0.05″x0.05″) HMIDMH10/HMIDMH15/HMIDMH17/HMIDMH20/HMIDMH25 H=1.0/1.5/1.7/2.0/2.5/mm (0.039′ 0.059′ 0.067’0.079′ 0.098′)
• Pitch 2.0 mm(0.079″) HMLSS15/HM LSS20 H=1.5/2.0 mm(0.059 /0.079 )
• Pitch 2.0mm(0.079″) HM LSR15/HM LSR20 H=1.5/2.0mm(0.059″/0.079″)
• Pitch 2.0 mm(0. 079 ” ) HMLSP15/HM LSP20 H=1.5/2.0 mm(0.059″/0.079”)
• Pitch 2.0 mm(0.079″) H MLSV15/HMLSV20/HMLSN15/HMLSN20 H=1.5/2.0 mm(0.059 IO. 079 )
• Pitch 2.0 mm(0.079″ ) H MLSSH15/H ML SSH20 H=1.5/2.0 mm(0.059 /0.079 )
• Pitch 2.0mm(0.079″) HM LSRH15/HM LSRH20 H=1.5/2.0mm(0.059″/0.079″)
• Pitch 2.0mm(0.07 9 ” ) HM LSVH 15/HMLSVH 20/HM LSNH15/HMLSN H20 H=1.5/2.0mm(0.059″/0.079″)
• Pitch 2.0 mm(0.079″) H MLDS1SIHM LDS20 H=1.5/2.0 mm(0.059 /0. 079” )
• pitch 2.0mm(0.079″) HM LDRI SIHM LDR20 H=1.5/2.0mm(0.059 ‘/0.079’ )
• Pitch 2.0 mm(0.079″) HMLDM15/H MLD M20 H=1.5/2.0 mm(0.059 IO.079 )
• Pitch 2.0mm(0.079″) HMLDM H15/HM LDMH20 H=1.5/2.0mm(0.059 /0.079 )
• Pitch 2.0 mm(0.079″) HMLDS43 H=4.3 mm(0.169″)
• Pitch 2.0 mm(0.079″) HM LDR43 H=4.3mm(0.169″)
• Pitch 2.0mm(0.07 9 ” ) HM LTR20 H=2.0mm(0.079”)
• Pitch 2.0 mm(0.079″) HMLQR20 H=2.0 mm(0.079″)
• Pitch 2.0 mm(0.079”) HF LSS40/H FLSS43/H FLSS46 H=4.0/4.3/4.6mm(0.157″/0.169″/0.181″)
• Pitch 2.0 mm(0.079″) HFLSR40/HFLSR43IHFLSR46 H=4.0I4.3/4.6mm(0.157″/0.169″10.181″)
• Pitch 2.0mm(0.079″) HF LSN40/HFLSN43/H FLS N46/ HF LSV40/H F LSV43/H F LSV46 H=4.0/4.3/4.6mm(0.157″/0.169″/0.181”)
• Pitc h 2.0mm(0.079″) H FLST43 H=4.3mm(0.169″)
• Pitch 2.0mm(0.079″) HF LSS63 H=6.3mm(0.248″)
• Pitch 2.0 mm(0.079″) HF LSR63 H=6.3mm(0.248″)
• Pitch 2.0mm(0.079″) H FLDS35 H=3.5mm(0.138″)
• Pitch 2.0mm(0.079 “) HFLD M35 H=3.5mm(0.138”)
• Pitch 2.0 mm(0. 079″ ) HF LDM20 H=2.0mm(0.079″)
• Pitch 2.0mm(0.079″) H FLDS63 H=6.3mm(0.248″)
• Pitch 2.0mm(0.079 “) HFLDR63 H=6.3mm(0.248”)
• Pitch 2.0 mm(0.079″) HF LDR63- T002 H=6.3mm(0.248″)
• Pitch 2.0mm(0.079 “) HFLDM63 H=6.3mm(0.248”)
• Pitch 2.0mm(0.079″) H FLDS40/H F LDS43/HF LDS46 H=4.0/4.3/4.6mm(0.157 /0.169 /0.181 ‘)
• Pitch 2.0mm(0.079 “) HFLDM40/HFLDM43/HFLDM46 H=4.0/4.3/4.6mm(0.157″/0.169″/0.181”)
• Pitch 2.0mm(0.07 9 ”) HFLDT43 -T002 H=4.3mm(0.169”)
• Pitch 2.0mm(0.079″) HF LDT45 -T001 H=4.5mm(0.177″)
• Pitch 2.0m m(0.07 9 ” ) HFLDR51 H=5.1mm(0.201 “)
• Pitch 2.0mm(0.07 9 ” ) HFLDM 51 H=5.1mm(0.201 “)
• Pitch 2.0 mm(0.079″) HFLDM51-P090 H=5.1mm(0.201 “)
• Pitch 2.0mm(0.07 9 ” ) HFLDS72 H=7.2mm(0.283”)
• Pitch 2.0 mm(0.079″) HFLDR72 H=7.2 mm(0.283″)
• Pitch 2.0mm(0.079″) HF LTS63 H=6.3mm(0.248″)
• Pitch 2.0 mm(0.079″) HF LTSH63 H=6.3mm(0.248″)
• Pitch 2.0mm(0.079″) HFLQS63 H=6.3mm(0.248″)
• Pitch 2.54mm(0.1″) HMNSS15/HM NSS20/HM NSS25 H=1. 5/2.0/2.5m m(0.059 ’/0.079 /0.098 )
• Pitch 2.54mm(0.1 “) HMNSR15/HM NSR20/H MNSR25 H=1.5/2.0/2.Smm(0.059″/0.079″/0.098”)
• Pitch 2.54mm(0.1 ”) HMNSN15/H MNSN 20/HM NSN25/ HMNSV15/HM NSV20/HM NSV25 H=1.5/2.0/2.5mm(0.059 /0.079 /0.098 )
• Pitch 2.54mm(0.1″) HMNSP25/HM NSP30 H=2.5/3.0mm(0.098”/0.118″)
• Pitch 2.54mm(0.1″) HMNSS H15/HMNSSH 25 H=1.5/2.5mm(0.059”/0.098″)
• Pitch 2.54mm(0.1 “) HM NSR H15/HM NSR H25 H=1.5/2.5mm(0.059″/0.098”)
• Pitch 2.54mm(0.1″) HMNSNH15/HMNSNH25/HMNSVH15/HMNSVH25 H=1.5/2.5mm(0.059 /0.098 )
• Pitch 2.54mm(0.1 “) HM NDS15/HM N DS25/HM NDS43 H=1.512.5/4.3mm(0.059″/0.098″/0.169”)
• Pitch 2.54mm(0.1″) HMNDR15/H MNDR25/H MNDR43/HM NDR74 H=1.5/2.5/4.3/7.4mm(0.059 /0.098 /0.169 /0.291 )
• Pitch 2.54mm(0.1″) HMN D M15/H MNDM25/HM NDM43 H=1.5/2.5/4.3mm(0.059″/0.098″/0.169″)
• Pitch 2.54mm(0.1″) H MNDP61 H=2.54mm(0.1 ”)
• Pitch 2.54mm(0.1 “) HM NDSH15/HM NDSH25 H=1.5/2.5mm(0.059″/0.098”)
• Pitch 2.54mm(0.1″) HMNDRH15/HM NDRH25 H=1.5/2.5mm(0.059″/0.098″)
• Pitch 2.54mm(0.1 ”) O HMNDMH15/HMNDMH25 H=1.5/2.5mm(0.059 /0.098′ )
• Pitch 2.54mm(0.1″) HMNTR15/HM N TR25 H=1.5/2.5mm(0.059”/0.098″)
• Pitch 2.54mm(0.1 “) HM NTS15/HM N TS25 H=1.5/2.5mm(0.059 /0.098 )
• Pitch 2.54mm(0.1 “) HFNSS57/HFNSS8Y H=5.7/8. Smm(0.224″/0.335”)
• Pitch 2.54mm(0.1″) HFNSSH 8YP H=8.5mm(0.335″)
• Pitch 2.54mm(0.1″ ) H FNS R57/H FNS R8Y H=5.7/8. Smm(0.224″/0.335″)
• Pitch 2.54mm(0.1″) HF NSS 50/H FNSS71IH F NSS85 H=5.0/7.1/8.5mm(0.197″/0.28″/0.335”)
• Pitch 2.54mm(0.1″) HFNSS68 H=6.8 mm(0.268″)
• Pitch 2.54mm(0.1 “) H FNS R50 H=5.0mm(0.197”)
• Pitch 2.54mm(0.1 “) HFNSVSO/HFNSV71/HFNSV85/ HFNSNSO/HFNSN71/HFNSN85 H=5.0/7.1/8.5mm(0.197″/0.28″/0.335”)
• Pitch 2.54mm (0.1 ” ) HFNST35/H FNSTSOI HFNST71 H=3.5I5.0/7.1 mm(0.138″/0.197″/0.28″)
• Pitch 2.54mm(0.1 “) HFNSR81 H=8.1mm(0.319”)
• Pitch 2.54mm(0.1″) HFNSM 81 H=8.1mm(0.319″)
• Pitch 2.54mm(0.1 “) HFN DS57/H FN DS8Y/HFNDS11 H=5.7/8.5/1.1 mm(0.224 /0.335 /0.043 )
• Pitch 2.54mm(0.1 “) HFNDSH 8YP H=8.5mm(0.335”)
• Pitch 2.54mm(0.1”) HFNDMH 8YP H=8.5mm(0.335″)
• Pitch 2.54mm(0.1 ”) HFN DR57/H FN DR8Y/H FNDR8T H=5.7/8.5/8. 5mm(0.224″/0.335”/0.335″)
• Pitc h 2.54mm (0.1 “) HFNDS35 H=3.5mm(0.138”)
• Pitch 2.54mm(0.1″) HFNDM35 H=3.5mm(0.138”)
• Pitch 2.54mm(0.1″) HFNDT35/H FN DT50/H FNDT71 H=3.5/5.0/7.1 mm(0.138″/0.197″/0.28″)
• Pitch 2.54mm(0.1″) HFN DSS0/H FN DS71/H FN DS85 H=5.0/7.1/8.5mm(0.197 /0.28 /0.335 )
• Pitch 2.54mm(0.1 “) HFN DS68 H=6.8mm(0.268”)
• Pitch 2.54mm(0.1″) HFNDM50/H FNDM71 H=5.0/7.1mm(0.197″/0.28″)
• Pitch 2.54mm(0.1 “) HFN D M 57/H FN D M 8Y/HFN D M11 H=5.7/8.5/1.1 mm(0.224”/0.335”/0.043”)
• Pitch 2.54mm(0.1″) HFNDTSO H=5.0 mm(0.197″)
• Pitch 2.54mm(0.1 “) HFNDT71 H=7.1mm(0.28”)
• Pitch 2.54mm(0.1″) HFNDR81 H=8.1 mm(0.319″)
• Pitch 2.54mm(0.1″) HFNDM 81 H=8.1 mm(0.319″)
• Pitch 2.54mm(0.1 “) HFNTS8Y H=8.5mm(0.335”)
• Pitch 2.54mm(0.1″) HFNTR8Y H=8.5mm(0.335″)
• Pitch 3.96mm(0.156″) HMPSS31 H=3.1 mm(0.1 22″)
• Pitch 3.96mm(0.156″) H MPSR31 H=3.1mm(0.122″)
• Pitch 5.08 mm(0.2 “) HMRSS25 H=2.5mm(0.098”)
• Pitch 5.08mm(0.2 ” ) HMRSV25/HMRSN25 H=2.5/2.5mm(0.098 ’/0.098”)
• Pitch 3.9 6mm(0.15 6 “) HMPSN 31/HMPSV31 H=3.1 mm(0.1 22”)
• Pitch 3.96 mm(0.156″) HM PSS H 31 H=3.1mm(0.122″)
• Pitch 3.96mm(0.156″) HF PSS89 H=8.8 mm(0.35″)
• Pitch 3.96 mm(0.156″) H FPSM 89 H=8.9mm(0.35″)
• Pitch 5.08 mm(0.2″) H MR SSH25 H=2.5/2.5mm(0.098″/0.098″)
• Pitch 5.08mm(0.2″ ) HFRSS89 H=8.9 mm(0.35″)
• Pitch 5.08mm (0.2 ” ) H FRSM89 H=8.9mm(0.35″)

Ürünlerle alakalı detaylı bilgi için info@adozmuhendislik.com adresine mail iletebilirsiniz.

PDF DOCUMENT DOWNLOAD
